Product Description
The PCE-MO 1500 is a professional insulation resistance tester designed to measure the insulation quality of electrical systems and components. It is suitable for testing motors, cables, switches, electrical installations, and insulating materials in industrial and maintenance applications.
The device provides selectable test voltages from 250 V to 2500 V DC and can measure insulation resistance up to 200 GΩ. It also supports AC/DC voltage measurement, data storage, and advanced analysis functions such as Polarization Index (PI) and Dielectric Absorption Ratio (DAR) for condition monitoring of electrical insulation.
Key Features
- Measures insulation resistance up to 200 GΩ.
- Selectable test voltages:
- 250 V DC
- 500 V DC
- 1000 V DC
- 2000 V DC
- 2500 V DC
- Measures AC and DC voltage.
- Functions:
- PI (Polarization Index)
- DAR (Dielectric Absorption Ratio)
- HOLD (Data Hold)
- Internal memory for up to 100 measurement records.
- Large 3.7-inch LCD display with backlight.
- Automatic discharge function after high-voltage testing.
- High-voltage warning indicator.
- Automatic power-off function.
- Safety rating: CAT III 1000 V / CAT IV 600 V.
Technical Specifications
DC Voltage Measurement
- Measuring Range: 10 – 600 V
- Resolution: 1 V
- Accuracy: ±(0.8% of reading + 5 digits)
AC Voltage Measurement
- Measuring Range: 10 – 600 V
- Resolution: 1 V
- Accuracy: ±(1% of reading + 5 digits)
Insulation Resistance
- Test Voltage: 250 V
- Test Voltage: 500 V / 1000 V
- Test Voltage: 2000 V / 2500 V
General Specifications
- Display: 3.7-inch LCD
- Memory Capacity: 100 readings
- Protection Rating: IP20
- Power Supply: 8 × AA 1.5 V batteries
- Weight: Approx. 651 g
- Dimensions: 140 × 180 × 70 mm
Applications
- Electrical insulation testing.
- Motor and generator maintenance.
- Cable insulation inspection.
- Testing electrical panels and installations.
- Preventive maintenance programs.
- Industrial equipment troubleshooting.
- Solar system insulation testing.
